Una-jet plastic corpus arida genus frigida aqua meter

In domo / Productio / Mechanicus aqua meter / Una-jet plastic corpus arida genus frigida aqua meter
Una-jet plastic corpus arida genus frigida aqua meter
  • Una-jet plastic corpus arida genus frigida aqua meter
  • Una-jet plastic corpus arida genus frigida aqua meter
  • Una-jet plastic corpus arida genus frigida aqua meter
  • Una-jet plastic corpus arida genus frigida aqua meter

KM05-23

Una-jet plastic corpus arida genus frigida aqua meter

Usus est pro familia aut residentialibus unitatibus ad mensuram, memoria, et ostentationem in volumine frigida aqua fluit per pipline.small magnitudine, lux pondere, simplex structuram, summus praecisione corporis testa processus, et internum plastic materia requisive.

Contact UsUna-jet plastic corpus arida genus frigida aqua meter
PREV: Single-jet aere corpus plastic operimentum arida genus frigida aqua meter NEXT:Single-jet immaculata corpus arida genus calida aqua meter
Una-jet plastic corpus arida genus frigida aqua meter

Descriptio

I. Features

  • Parvum magnitudine leviora pondere
  • Type adopt unum jet, plastic corporis consilio.
  • Arido typus Register, magnetica coegi, anti-magnetica intercessiones, anti-glacians, diu terminus patet Lectio, tamper probationem
  • Materiam: ære, ferrum, plastic corpus optionem
  • Non-reditus valvae et colatorium is available
  • Ausi a GLAREUS et particulates
  • Dum ducere sigillum et pulvis-probationem operimentum
  • Confírma est ISO4064
  • Available ad IP68

II. Caput damnum curva

III. ERROR curva

IV. Installation dimensionem

Item non LXSG, XV
L mm 110
L1 mm 205
H mm 75
W mm 75
Filum D (mm) G3 / IV "
d (mm) R1 / II
Pondus sine unionibus
kg 		0.5kg

V. Main Technical Data

Model Number

LXSG, XV

Nominis diameter (DN) [mm]

15

20

25

32

40

Ratio Q3 / Q1

R80

R100

R160

R80

R100

R160

R80

R100

R160

R80

R100

R160

R80

R100

R160

ONERO fluxus rate (Q4) [M³ / h]

3.125

3.125

3.125

5

5

5

7.875

7.875

7.875

12.5

12.5

12.5

20

20

20

Permanent fluxus rate (Q3) [M³ / h]

2.5

2.5

2.5

4

4

4

6.3

6.3

6.3

10

10

10

16

16

16

Transitional fluxus rate (Q2) [M³ / h]

0.05

0.04

0.025

0.08

0.064

0.04

0.126

0.1

0.063

0.2

0.16

0.1

0.32

0.256

0.16

Minimum fluxus rate (Q1) [M³ / h]

0.032

0.025

0.015

0.05

0.04

0.025

0.08

0.063

0.039375

0.125

0.1

0.0625

0.2

0.16

0.1

Genus accuracy

2

Maximum permissibilis error

Nam inferioribus influunt rate zona (MPEAC)

± V%

Maximum permissibilis error

Nam superius fluunt rate zona (MPEμ)

± II% ad aquam habens temperatus ≤30 ℃

± III% ad aquam habens temperatus> XXX ℃

Genus temperatus

T30, T50

Aqua pressura classes

Map XVI

Pressura-damnum classes

△ P63

Significat range [M³]

XCIX CMXCIX

Resolutio
Significans fabrica [M³]

0.00005

Flue profile sensum classes

U10 D5

Orientatio limitation

Horizontal
